OmniVision three-layer stacked sensor

Image Sensors World        Go to the original article...

From Businesswire --- "OMNIVISION Announces World’s Smallest Global Shutter Image Sensor for AR/VR/MR and Metaverse".

OmniVision has announced the industry’s first and only three-layer stacked BSI global shutter (GS) image sensor. The OG0TB is the world’s smallest image sensor for eye and face tracking in AR/VR/MR and Metaverse consumer devices, with a package size of just 1.64mm x 1.64mm, it has a 2.2µm pixel in a 1/14.46-inch optical format (OF). The CMOS image sensor features 400×400 resolution and ultra-low power consumption, ideal for some of the smallest and lightest battery-powered wearables, such as eye goggles and glasses. Ultra-low power consumption is critical for these battery-powered devices, which can have 10 or more cameras per system. Their OG0TB BSI GS image sensor consumes less than 7.2mW at 30 frames per second (fps).



SANTA CLARA, Calif.--(BUSINESS WIRE)--OMNIVISION, a leading global developer of semiconductor solutions, including advanced digital imaging, analog, and touch & display technology, today announced the industry’s first and only three-layer stacked BSI global shutter (GS) image sensor. The OG0TB is the world’s smallest image sensor for eye and face tracking in AR/VR/MR and Metaverse consumer devices, with a package size of just 1.64mm x 1.64mm, it has a 2.2µm pixel in a 1/14.46-inch optical format (OF). The CMOS image sensor features 400x400 resolution and ultra-low power consumption, ideal for some of the smallest and lightest battery-powered wearables, such as eye goggles and glasses.

“OMNIVISION is leading the industry by developing the world’s first three-layer stacked global shutter pixel technology and implementing it in the smallest GS image sensor with uncompromising performance,” said David Shin, staff product marketing manager – IoT/Emerging at OMNIVISION. “We pack all of these features and functions into the world’s smallest ‘ready-to-go’ image sensor, which provides design flexibility to put the camera in the most ideal placement on some of the smallest and slimmest wearable devices.” Shin adds, “Ultra-low power consumption is critical for these battery-powered devices, which can have 10 or more cameras per system. Our OG0TB BSI GS image sensor consumes less than 7.2mW at 30 frames per second (fps).”

The worldwide market for AR/VR headsets grew 92.1% year over year in 2021, with shipments reaching 11.2 million units, according to new data from the International Data Corporation (IDC) Worldwide Quarterly AR/VR Headset Tracker1. New entrants as well as broader adoption from the commercial sector will propel the market further as headset shipments are forecast to grow 46.9% year over year in 2022. In fact, IDC expects this market to experience double-digit growth through 2026 as global shipments of AR/VR headsets surpass 50 million units by the end of the forecast, with a 35.1% compounded annual growth rate (CAGR).

OMNIVISION is supporting the growing market for AR/VR headsets by introducing new products such as the OG0TB GS image sensor, which features the company’s most advanced technology:

 It is built on OMNIVISION’s PureCel®Plus-S stacked-die technology.

 It features a three-layer stacked sensor with pixel size at 2.2µm in a 1/14.46-inch OF to achieve 400x400 resolution.

 Nyxel® technology enables the best quantum efficiency (QE) at the 940nm NIR wavelength for sharp, accurate images of moving objects.

 The sensor’s high modulation transfer function (MTF) enables sharper images with greater contrast and more detail, which is especially important for enhancing decision-making processes in machine vision applications.

 The sensor supports a flexible interface, including MIPI with multi-drop, CPHY, SPI, etc.

The OG0TB GS image sensor will be available for sampling in Q3 2022 and in mass production in the 2H 2023.


PS: It is worth noting that Sony made a claim for "world's first 3 layer stacked CIS" back in 2017 after their ISSCC paper titled "A 1/2.3inch 20Mpixel 3-layer stacked CMOS Image Sensor with DRAM" (DOI: 10.1109/ISSCC.2017.7870268). The three layers consisted of photodiodes, DRAM memory, and mixed-signal ISP. But that was a rolling shutter sensor, whereas this one from OmniVision is a global shutter sensor.

PPS: Readers of blog who know of any journal or conference publication about OmniVision's new design please share them in the comments below!


Go to the original article...

STMicro and trinamiX collaboration on face authentication

Image Sensors World        Go to the original article...

https://www.yolegroup.com/industry-news/stmicroelectronics-and-trinamix-collaborate-on-behind-oled-face-authentication-solution-to-be-showcased-live-at-ifa-2022/

STMicroelectronics and trinamiX collaborate on behind-OLED face-authentication solution to be showcased live at IFA 2022

  • Companies will demonstrate full facial authentication solution for smartphone integration and for applications behind OLED screens
  • Solution combines high-performance near-infrared global-shutter image sensor from ST and sophisticated trinamiX algorithm
  • Certified for use in mobile payments according to IIFAA, AndroidTM, and FIDO standards


STMicroelectronics, a global semiconductor leader serving customers across the spectrum of electronics applications, and trinamiX, a wholly owned subsidiary of BASF SE and pioneer of new biometric technologies, today announced their collaboration on a reference design for face authentication. The solution performs behind an OLED screen and on the security level required for mobile payments. A demonstration of this system will be first presented live at IFA 2022 in Berlin on September 2-6.

The joint development and reference design for smartphone OEMs is a full system implementation that integrates illumination, a camera module that combines ST’s global-shutter image sensor with enhanced near-infrared (NIR) sensitivity (VD56G3), and trinamiX’s patent-protected algorithms running on the processor. The system offers a contactless, fast, and reliable authentication method for integration into smartphones and other products requiring user authentication. The solution’s strength lies in a unique technology, which uses skin detection to verify a user’s liveness. In addition to verifying the user’s identity, it effectively differentiates between skin and other materials, to recognize fake presentations like photos, hyper-realistic masks, and deepfakes.

"The collaboration with ST provides us with very small, high-performance image sensors at a competitive price point. This is particularly important for our products in the consumer electronics sector," said Stefan Metz, Head of Smartphone Business Asia at trinamiX. “Furthermore, trinamiX Face Authentication can fully operate behind OLED while maintaining the highest security levels. If required, the high NIR sensitivity of ST’s image sensors supports the easy integration of our solution behind display.” According to Metz, smartphone manufacturers are thus offered a powerful, attractive package: “During the development of our smartphone reference design, we focused on particularly compact hardware sizes without compromising the performance.”

"ST’s advanced image sensors use the company’s process technologies that enable class-leading pixel size while offering both high sensitivity and low crosstalk, delivering significant improvements in performance, size, and system integration. The collaboration with trinamiX provides ST with additional opportunities to extend our support to technologies, use cases, and ecosystems addressing the thriving under-display market in Personal Electronics and beyond," said David Maucotel, Head of the Personal Electronics, Industrial and Mass Market Product Business Line at ST’s Imaging Sub-Group.

In 2021, trinamiX Face Authentication was approved for Android integration and certified according to the high biometric security requirements of Android Biometric Class 3, IIFAA Biometric Face Security Test Requirement, and FIDO Level C – the FIDO alliance’s soon-to-be top standard.

A demonstration of the joint system for face authentication will debut at IFA 2022, taking place in Berlin, Germany on September 2-6. Customer presentations as well as appointments during the fair can be requested at info@trinamiX.de.

Go to the original article...

Fujifilm XH2 review

Cameralabs        Go to the original article...

The Fujifilm X-H2 is a high-end mirrorless camera with a new 40 Megapixel APSC sensor and 8k video. Check out my hands-on review so far!…

Go to the original article...

Yole interview with OmniVision’s marketing director

Image Sensors World        Go to the original article...

https://www.yolegroup.com/player-interviews/security-imaging-industry-omnivision-delivers-state-of-the-art-performance-products/

Security has become the largest CMOS image sensor market segment after mobile and computing devices. From 2021 to 2027, according to Yole Intelligence’s latest report, Imaging for Security 2022, revenue is expected to increase from $2.1 billion to $3.6 billion at a 9% Compound Annual Growth Rate (CAGR). 2020 and 2021 were exceptional years for the security CIS segment, and IP security cameras still provide a major growth opportunity.



Security imaging is sustained by the growing need for security everywhere: in consumer, commercial, and infrastructure monitoring applications, driven by the increasing adoption of home Internet of Things (IoT) solutions, the demand for video analytics in retail and monitored buildings, the need for more touchless access control solutions, the development of public surveillance in cities and for critical infrastructure. The rise of video analytics, edge computing, and the development of AI vision processors enable a wider range of products.



Florian Domengie, Senior Analyst in the Imaging team at Yole Intelligence, had the opportunity to discuss with Devang Patel, Marketing Director of IoT/Emerging Segment at OMNIVISION, about the recent activities of the company and the current trends in the field of security imaging.

Florian Domengie (FD): Please introduce yourself and OMNIVISION to our readers.

Devang Patel (DP): I am OMNIVISION’s Marketing Director and have a long history in the semiconductor industry in various roles. My missions were dedicated to product management/planning, strategic marketing, and partnerships.
OMNIVISION is a global fabless semiconductor organization that develops advanced digital imaging, analog, and touch & display solutions for multiple applications and industries, including mobile phones; security and surveillance; automotive; computing; medical; and emerging applications. Its award-winning innovative technologies enable a smoother human/machine interface in many of today’s commercial devices.

FD: What new products has OMNIVISION released recently? Which applications are you targeting with these new products?


DP: From the security side, our company continues to be at the leading edge in providing discreet, energy-efficient power management solutions as well as the best interface protection products on the market. Indeed, thanks to the emergence of the Internet of Things (IoT), surveillance cameras are no longer limited to enterprise applications such as airports, train stations, banks, and office buildings. Instead, they have become an integral part of retail establishments, smart cities, and smart homes for the purpose of gathering and analyzing Big Data.
Here are a few examples of products developed by our experts:
 OMNIVISION’s OS03B10 CMOS image sensor brings high-quality digital images and high-definition (HD) video to security surveillance, IP, and HD analog cameras in a 3-megapixel (MP) 1/2.7-inch optical format (OF). The OS03B10 image sensor features a 2.5 micron (µm) pixel based on OMNIVISION’s OmniPixel®3-HS technology. The high-performance, cost-effective solution uses high-sensitivity frontside illumination (FSI) to detect objects better than the human eye for true-to-life color reproduction in bright and dark conditions.
 OMNIVISION’s OS02H10 is a 2.9µm, 1080p image sensor that provides a high-value option for adding the premium near-infrared (NIR) and ultra-low light performance of its Nyxel® and PureCel®Plus technologies to mainstream surveillance cameras. This sensor also offers multiple high dynamic range (HDR) options for the best quality 1080p still and video captures of fast-moving objects at 60 frames per second (fps). The OS02H10 provides a high-value option for adding premium near-infrared (NIR), ultra-low light, and HDR performance to high-volume, mainstream security systems with AI functionality. It also offers an ultra-low power mode that consumes 97.7% less power than the normal mode to support long battery life.
 OMNIVISION’s OS04C10 is a 2.0µm pixel, 4 MP resolution image sensor for both IoT and home security cameras. When paired with the designer’s selected platform, the OS04C10 can enable a system’s ultra-low power mode for battery-powered cameras with AI functionality. Additionally, it provides a high 2688 x 1520 resolution with a 16:9 aspect ratio while adding the premium NIR and ultra-low light, SNR1 performance of its Nyxel® and PureCel®Plus technologies. This sensor also offers multiple HDR options for the highest quality 4MP still and video captures of fast-moving objects at 60fps. The OS04C10 is built on the PureCel®Plus pixel architecture to achieve a superior low-noise design, providing an SNR1 that is 150% better than OMNIVISION’s prior-generation OV4689 4MP mainstream security sensor.


FD: There has been very significant growth in CMOS imaging products for the security market these last two years. How do you explain this evolution? What benefits do these bring to this market specifically?

DP: There are many factors. We see that the home security market is growing, including DIY battery-powered types of cameras. You can basically install them by yourself. The number of companies getting into this specific product line is growing.
The second factor is infrastructure. Lots of cities worldwide are adding artificial intelligence to their surveillance. For example, looking at intersections, train stations, and airports, we have seen that the city surveillance infrastructure needs growth supported by government initiatives.
The third factor is AI, which is the big thing that brings higher-resolution cameras into this market.
At Yole Intelligence, part of Yole Group, we have noticed increasing opportunities in all the security imaging market segments: consumer, commercial, and infrastructure.

FD: Which types of applications are becoming popular, and what will sustain growth in the security market in the years to come?

DP: I think commercial, and infrastructure are steadier markets, and we expect them to continue to grow. If you look at the CAGR, infrastructure has slowed down a little during the pandemic. On the consumer side, the need for “smart home” has increased. We have seen a CAGR of about 20% for “smart home”, while the traditional consumer commercial security CAGR is about 11%. As a result, we expect both security imaging market segments, commercial and infrastructure, will continue to grow in the coming years.

FD: Have you seen an increasing penetration of 3D sensing into surveillance and security applications?

DP: So far, it has not been huge. We have seen 3D sensing mentioned for some authentication use cases, but it’s mainly applied to indoor access.

FD: As a leading supplier of CMOS image sensors for security imaging, how do you see the competitive landscape and market demand develop? Is there any geographic differentiation between Europe, America, and Asia?

DP: On the overall landscape, we see that the 1080p resolution market is very competitive and is essentially replacing 720p, which used to be the low end. If you look at the product portfolio from OMNIVISION, as well as our competitors, you will see that more and more 1080p cost-sensitive products are being brought into the market.
In terms of geographical differentiation, 1080p seems to be the norm across the globe. Some applications like doorbells and smart home cameras are looking for higher resolution. Some applications like doorbells and smart home cameras are focusing on higher resolution so that they can deploy AI. To better enable AI, Some applications at the very high end would even deploy 4K2K resolutions. When it comes to city or street surveillance, high resolution is needed for counting the number of people or vehicles or for zooming in for detail. However, that market is small compared to 1080p.
While the race for smaller pixels and increased resolution is still ongoing for mobile, it seems less important for security applications where image quality is preferred.

FD: What is the trend in sensor resolution for security applications? What are the most critical performance parameters?

DP: As we mentioned previously, the resolution trend is not as severe in security compared to the smartphone market. The three key buckets we see in security are firstly the 1080p, which is roughly 2MP. Then the next bucket is 4 or 5MP, and at the high end is the 4K2K. From a volume point of view, the 1080p is by far the lion’s share. The 4 and 5MP would be the next, and then 4K2K are very high-end in terms of critical performance.
The key parameter in security is still low light sensitivity: in low light, how good is your camera? So typically, a larger pixel is used in the market. So, in the security market today, the smallest pixel we see is 1.45μm. Slowly, the smaller pixels are being deployed in security, but the majority are still large pixels.
Lower power consumption is critical for numerous applications, particularly battery-powered consumer security cameras.

FD: How can you address this with your products?

DP: To enable longer battery power, we have a unique solution called always-on architecture. Essentially, we provide a total system approach that involves a sensor with our own video processor that enables very low-power system solutions. We are taking our low-power architecture to a new level with a product we will launch later this year.

FD: There is a trend to bring more video analytics and Artificial Intelligence into security camera products. What is OMNIVISION’s view on this?

DP: Video analytics and AI are hot topics in the industry. We expect video analytics and AI technology, which used to be only at the high end a few years ago, to come down to mid-range or entry-level.
One of the key requirements on the sensor side is providing higher resolution so that you can do video analytics and AI functions simultaneously. To address this need, we have a portfolio of 4 and 5MP image sensors, all the way up to 4K2K, for our customers.

FD: Is there any other message you would like to share with our readers and the industry?

DP: In summary, we see 1080p as the dominant resolution for the foreseeable future. A higher resolution is needed for video analytics and AI applications. Always-on is one of the key features demanded for low-power battery cameras.
Low-light pixel performance is still one of the key criteria for security cameras. At OMNIVISION, we have a product line that addresses low light performance that goes from 1080p all the way to 4K2K. We also provide low-power video processors enabling a long-lasting battery solution.

Go to the original article...

Viltrox AF 35mm f1.8 review

Cameralabs        Go to the original article...

The AF 35mm f1.8 from Viltrox is a mild wide prime lens designed for mirrorless full-frame cameras with Nikon Z-mount or Sony E-mount. Is it a good alternative to Nikon's and Sony's 35mm f1.8 lenses? Find out in my in-depth review!…

Go to the original article...

CineD tests ARRI ALEXA 35 cinematography sensor

Image Sensors World        Go to the original article...

In June, this blog shared the announcement of ARRI's new cinematography sensor ALEXA 35.

Last week CineD published a "lab test" of this sensor. CineD is an independent website that reviews latest advances in cinematography technology,

https://www.cined.com/arri-alexa-35-lab-test-rolling-shutter-dynamic-range-and-latitude-plus-video/






Go to the original article...

Canon announces “Lithography Plus” solution platform offering Canon’s support know-how to help maximize productivity for semiconductor lithography systems

Newsroom | Canon Global        Go to the original article...

Go to the original article...

EETimes Europe article on emergence of consumer and automotive SWIR imaging

Image Sensors World        Go to the original article...

An article in EETimes Europe from August 24, 2022 argues that huge changes are happening in the consumer and automotive SWIR imaging industry. Some excerpts below.

https://www.eetimes.eu/how-smartphones-will-disrupt-the-swir-imaging-industry

How Smartphones Will Disrupt the SWIR Imaging Industry

August 24, 2022 Axel Clouet and Eric Mounier

Sensing SWIR radiation requires imagers based on other materials, making them orders of magnitude more expensive than silicon-based imagers. Therefore, SWIR’s use today is limited to specific applications in defense, industry, or research.

... [A] pull from the consumer market is inspiring unprecedented changes in the SWIR industry, with the emergence of new technologies and the entrance of game-changing players who may enable market and technology disruption.

A newer technology, based on quantum dots (QDs), is emerging as a lower-cost alternative to InGaAs. ... with a manufacturing process that is compatible with CMOS, allowing cost reductions by orders of magnitude.

QD technology is still emerging, with the first commercial products released in 2018 for the industry by SWIR Vision Systems.

SWIR’s technology development will be accelerated by the entrance of game-changing players: Sony released its first commercial SWIR imager in 2020, and in 2021, STMicroelectronics announced the development of SWIR imagers based on QDs. ... [both are] leading companies in the consumer and automotive silicon-based imaging industry. Sony introduced a manufacturing method based on copper-to-copper bonding, inherited from its know-how in silicon-based imaging, to make InGaAs SWIR imagers. STMicroelectronics published initial results for its SWIR imagers based on QD technology ... demonstrated high sensitivity, optimized at about 1.4 µm.

[Yole Intelligence] expect[s] the number of industrial cameras to increase significantly in the coming years, thanks to price decreases linked to QD technology penetration and the introduction of new manufacturing processes for InGaAs. These segments could represent a US$828 million market in 2027 at the camera level.

[Since] an artificial SWIR source needs to be used in combination with the imaging system. The SWIR source market should therefore benefit from the growth of the SWIR imaging market. SWIR edge-emitting diode lasers (EELs) are widely used today in the telecommunications market, ... SWIR vertical-cavity surface-emitting lasers (VCSELs) should strongly benefit from the emerging consumer and automotive SWIR markets.





Go to the original article...
